DDC Network Expansion Controller
BICC-0080K
It is applied in building automation systems or industrial fields to connect common control equipment, such as sump pits, supply and exhaust fans, fresh air handling units, air handling units, water pumps, central air conditioning, elevators, fire protection and lighting control.
BICC-0080K is used in building automation systems. It connects to the DDC network IP expansion controller via its left network port to access the system. See Figure 1-1 for the connection method. The left port of the module communicates with the main module for expansion, and the right port connects other expansion modules into the system. It supports multiple IO expansion modules and special function modules. Up to 4 IO modules can be connected under normal conditions. The maximum number of connected expansion modules depends on the power output capacity of the module.
| 2 LAN Ports | Operating Voltage: 24VDC; |
|---|---|
| AI Input: 8 channels for 0-10V/4-20mA input | Relative Humidity: Max 90% |
| Operating Temperature: -5℃~+45℃ | Storage Temperature: -10℃~+55℃ |
| Operating Current: >1A | Mounting: 35mm DIN rail mounting |
(1) Read all instructions carefully before use.
(2) Maintain a well-ventilated environment.
(3) Protect against moisture, vibration and dust during operation.
(4) Do not expose to rain, liquids or corrosive gases.
(5) Dry the device immediately if it gets wet or contaminated by liquid.
(6) In case of equipment malfunction, please contact professional maintenance personnel or our company.
