DDC Network IP Controller
BICC-8800T
BICC‑8800T is a DDC network IP main controller for building automation systems. It connects to the device network via Ethernet cable and features dual network ports for cascading BICC series expansion controllers. As the main module, it can be connected to external IO expansion modules and special function modules to expand control points and functions. Up to 4 IO modules can be extended under normal conditions, and the actual number of connectable expansion modules is limited by the output power supply capacity of the main unit. Designed for building automation and industrial control applications, this product can interface with various field-controlled equipment such as sump pits, supply and exhaust fans, fresh air units, air handling units, water pumps, central air conditioning, elevators, fire protection systems and lighting, to meet the centralized control requirements of various automation projects.
- Standard Ethernet port for connection to DDC device network, operating as the system main controller;
- Dual network ports with separate functions: the left port connects to the upper-level device network, and the right port cascades lower-level expansion modules;
- Supports mounting of IO expansion modules and special function modules to expand system points and functions, normally up to 4 IO modules;
- The number of accessible expansion modules is limited by the output power of the controller;
- Compatible with various field equipment such as fans, air conditioners, water pumps, elevators, fire protection systems and lighting;
- Realizes data exchange between the main device and expansion modules under the complete DDC network for unified equipment management and control.
| 2 LAN Ports | Operating Voltage: 24VDC |
|---|---|
| DI Input: 8 isolated digital input channels | DO Output: 8 relay output channels |
| Communication Interface: 2 RS485 universal serial ports | Baud Rate: RS485 / 9600bps |
| Operating Temperature: -5℃ ~ +45℃ | Storage Temperature: -10℃ ~ +55℃ |
| Operating Current: >1A | Mounting: 35mm DIN rail mounting |
(1) Read all instructions thoroughly before use.
(2) Ensure a well-ventilated environment.
(3) Keep away from moisture, vibration and dust during operation.
(4) Never expose to rain, liquid or corrosive gas.
(5) Dry the unit promptly if it gets wet or contaminated by liquid.
(6) In case of equipment failure, contact professional maintenance personnel or our company.
