DDC Network Expansion Controller
BICC-8800K
BICC‑8800K is a dedicated DDC network expansion controller for building automation systems. Equipped with a dual network port communication architecture, it enables network cascading between the main DDC module and lower-level expansion modules. External IO expansion modules and special function modules can be connected to expand system IO points and functions. The number of accessible expansion modules is limited by power supply capacity, normally up to 4 IO modules. Suitable for building automation and industrial control scenarios, it can connect to various controlled equipment such as fresh air units, air handling units, water pumps, supply and exhaust fans, sump pits, elevators, fire protection systems and lighting, flexibly meeting the point expansion requirements of projects.
- Dual network port design: the left port communicates with the main module, and the right port is used to cascade other expansion modules;
- Supports external IO expansion modules and special function modules to expand system points and functions, normally up to 4 IO modules;
- The number of accessible expansion modules is determined by the output power capacity of the device;
- Suitable for building automation and industrial control scenarios, compatible with various field controlled equipment such as fans, air conditioners, water pumps, lighting and fire protection systems;
- Completes data exchange of expansion devices via DDC network to realize unified management of the whole control system.
| 2 LAN Ports | Operating Voltage: 24VDC; |
|---|---|
| DI Input: 8 isolated digital input channels | DO Output: 8 relay output channels |
| Operating Temperature: -5℃~+45℃ | Storage Temperature: -10℃~+55℃ |
| Operating Current: >1A | Mounting: 35mm DIN rail mounting |
(1) Read all instructions carefully before use.
(2) Maintain a well-ventilated environment.
(3) Protect against moisture, vibration and dust during operation.
(4) Do not expose to rain, other liquids or corrosive gases.
(5) Dry the device immediately if it gets wet or contaminated by liquid.
(6) In case of equipment malfunction, contact professional maintenance personnel or our company.
