DDC Network IP Controller
BICC-FF00T
BICC‑FF00T is a DDC network IP main controller for building automation systems. It connects to the device network via Ethernet cable. Its dual-port architecture supports cascading DDC network expansion controllers. As the main system module, it can be connected to external IO expansion modules and special function modules to expand control points and system functions. Normally up to 4 IO modules can be extended, and the actual number of mountable expansion modules is limited by the output power supply capacity of the main unit. Suitable for building automation and industrial control fields, this product can interface with various field-controlled equipment such as sump pits, supply and exhaust fans, fresh air units, air handling units, water pumps, central air conditioning, elevators, fire protection systems and lighting to realize centralized monitoring and management of field devices.
- Connect to the DDC device network via Ethernet cable and operate as the main controller in the automation system;
- Dual network port design with separate functions: the left port connects to the upper-level device network, and the right port cascades various downstream expansion modules;
- Supports external IO expansion modules and special function modules to expand points and functions, normally up to 4 IO modules;
- The maximum quantity of external expansion modules is determined by the output power of the controller;
- Suitable for building automation and industrial control scenarios, compatible with various field equipment such as fans, air conditioners, water pumps, elevators, fire protection systems and lighting;
- Realizes data exchange between the main controller and downstream expansion modules to achieve unified monitoring and management of field devices.
| 2 LAN Ports | Operating Voltage: 24VDC; |
|---|---|
| DI Input: 16 isolated digital input channels | DO Output: 16 relay output channels |
| Communication Interface: 2 RS485 universal serial ports | Baud Rate: RS485 / 9600bps |
| Operating Temperature: -5℃~+45℃ | Storage Temperature: -10℃~+55℃ |
| Operating Current: >1A | Mounting: 35mm DIN rail mounting |
(1) Read all instructions thoroughly before use.
(2) Ensure a well-ventilated environment.
(3) Keep away from moisture, vibration and dust during operation.
(4) Do not expose to rain, other liquids or corrosive gases.
(5) Dry the device promptly if it gets wet or contaminated by liquid.
(6) In case of equipment failure, please contact professional maintenance personnel or our company.
